Innovation intersects tradition

Key specifications

Motor output 610 W
Revolutions per minute 1290 rpm
Ø Burrs 83 mm
Espresso point production 15 kg/h
Time x dosis Espresso (7 g) 1,6 s
Hopper capacity 1.700 g
Height x width x depth 680 x 215 x 400 mm
Net weight 13 kg

Key features

"Parallel System" grind regulator lock

1 or 2 On-Demand ground coffees

Recognition of up to 10 portafilters

Hands free for the barista

Touch control screen

Motor with fan

Three positions switch with by-pass

Electronic features

Multilanguage display

4 Modes: Pre-selection - Automatic - Instant - Manual

Protection menu access by password

Total and partial shot counter

Notice of change of burrs

Quantity lock configurable by weight ground


Motor 730 W to 1.350 rpm

Powerful motor that allows you to work continuously in situations of high demand, maintaining all the properties of the coffee thanks to the cold grinding at low revolutions.

Flat 83 mm burrs

Ensures accurate particle size for Espresso and spectacular productivity: 7 g in 1.6 seconds. Special pre-wear treatment is applied to ensure optimal performance from the first use. Durability of 800 Kg.

LCD Display Essential DBW

Multilanguage. Changing burrs alarm.
4 Modes: Pre-selection, Automatic, Instant and Manual. Refill Button. Absolute and relative coffees counting. Activate pad and end of service sound. Password.

Continuous micrometric adjustment system Parallel

Set the grind point with maximum precision in a very simple and intuitive way. The new Parallel locking system provides an extra level of security ensuring parallel positioning between burrs at all times.

Sistema de iluminación mediante LEDS

Low consumption LED technology, which will allow the final user to have a greater visibility in their working area.

Accurate dosing.
Average grinding Speed*: 4,5g/s

* Based on a medium-roasted coffee and an Espresso grind. May vary depending on the degree of fineness.

Dose by weight

Scale. Consistently accurate doses.
Dosing by a pre-set weight. Forget about dosing by timer or dosing by volume.

Three position switch

Offers total control to the Barista without been necessary to use the electronical system of the grinder.


Burrs Red Speed Lucidate

Lower friction, lower temperature. Upon this premise, we have developed Lucidate Speed Red burrs. Even after 3.000 Kg of coffee, the burrs will perform as if it were their first day of use thanks to the low coefficient of friction and specially hardened material.


Technical data files


ETL Listed
ETL Sanitation
Food Contact
KC Certification
